C363DT

Revel in-ceiling loudspeakers draw upon the same research, resources, and unique perspectives that put all our loudspeakers in a class by themselves. Each model offers a standard-setting low sonic coloration and freedom from distortion over a wide dynamic range.

C363DT HIGHLIGHTS

• Long-throw woofers with cast frames and rubber surrounds provide high output with low distortion.

• 1-inch (25mm) angle-adjustable, metal-dome tweeter with an integrated waveguide provides optimized response both on and off axis.

• High-order crossover network with premium-quality components delivers extraordinarily accurate timbre reproduction.

• Boundary compensation switch (C783/C763) lets you adjust the speaker to maintain tonal accuracy when the speaker is placed near a wall.

• Three-position tweeter level control (C783/C763/C583/C563) lets you adjust for optimum response in a variety of acoustical environments, or for using the speakers without grilles.

  Height	Cutout dimensions (dia.) 8" (20.3 cm)  Square grille finished Height 9.1" (23.1 cm)
  Width	Square grille finished Weight 9.1" (23.1 cm
  Depth	Mounting depth 4.8” (12.2 cm)
  Weight	1.9Kg
  Features	Includes both round and square zero-bezel magnetic grilles  Round grille finished dimension (dia.) 9.1" (23.1 cm)
  High Frequency Driver Components	Two 1" aluminum dome tweeters with waveguides
  Low Frequency Driver Components	6 ½" Micro-Ceramic Composite (MCC) Cone  Cast-Aluminum Frame Woofer
  Mounting	C-2 fastening mechanism  Compatible with wall material thickness range 0.5" – 2.0" (1.3 cm – 5.0 cm)
  Recommended Amplifier Power	10 - 120 Watts RMS (per channel)
