The JBL Studio 698 is the flagship floor-standing speaker of the company's impressive Studio 6 lineup. It features dual 8" PolyPlas® woofers in a double-ported enclosure for deep, powerful bass, plus a dedicated 6" midrange driver. High frequencies are handled by a 1" horn-loaded tweeter with HDI (High Definition Imaging) waveguide technology that delivers detailed sound across a wide listening area.

 We recommend giving this speaker high-current amplification from a quality power amp or integrated amplifier for best performance. Dual binding post speaker terminals allow bi-amping or bi-wiring.

 Built on JBL's storied audio heritage

 JBL famously pioneered horn-loaded compression drivers in speaker arrays at large concert venues — they're able to fill space with clear sound in a way a standard dome tweeter can't.

 The cornerstone of the Studio 6 Series' distinctive sound is JBL's 1" compression driver mated to a High-Definition Imaging (HDI) horn. The proprietary design helps this speaker deliver crystal-clear high frequencies throughout your room.

 Product highlights

• 3-way design
• 1" compression driver with HDI (High Definition Imaging) waveguide technology for clear highs across a wide listening area
• 6" PolyPlas® midrange driver for engaging detail with instruments and vocals
• dual 8" PolyPlas® cone woofers for deep, powerful bass
• bass-reflex cabinet design with dual rear-firing ports
• frequency response: 36-40,000 Hz
• sensitivity: 90 dB
• impedance: 6 ohms
  • high-current amplification from a quality power amp or integrated amplifier is recommended for best performance
• power handling: up to 250 watts
• two sets of binding post speaker terminals allow bi-amping or bi-wiring
• removable magnetic grille

• Specifications

  Enclosure	Ported
  Tweeter	Compression Horn
  Tweeter Size (inches)	1
  Midrange Size (inches)	6
  Woofer Size (inches)	8
  Woofer Composition	PolyPlas
  Woofer Surround	Rubber
  Built-in Powered Sub	No
  Dolby Atmos Drivers	No
  Connector Type	5-Way post
  Bi-amp Inputs	Yes
  Parts Warranty	5 Years
  Labor Warranty	5 Years
  Power Range	up to 250
  Frequency Response	36-40k Hz
  Sensitivity	90 dB
  Impedance (Ohms)	6
  Subwoofer Amp Power	--
  Height (inches)	43-1/4
  Width (inches)	11-3/4
  Depth (inches)	16-1/16
  Weight	79 lbs
