Marantz
Marantz SA-10 Premium Series
Marantz SA-10 Premium Series
Couldn't load pickup availability
It Starts with the Disc
Whether playing SACDs, CDs, or other data discs containing music, it's vital that any player retrieves the information as accurately as possible: unlike a computer reading a disc for ripping, there's no time for repeated re-scans when playing music - it happens in real time, so the disc transport needs to get things right first time.
CDs, SACDs and Beyond
The SA-10 goes so much further than just disc playback: it's also a fully-functional digital-to-analog converter for music stored on a home computer, as well as having conventional digital inputs for existing source components. Those conventional inputs - optical and coaxial - can handle your music files up to 192kHz/24bit.
More than just a DAC
The SA-10 takes things further - just as it features an all-new disc transport mechanism, so the digital to analogue conversion has also been subject to a radical rethink, taking full advantage of the 1-bit conversion technology found in past flagship Marantz players, and incorporating brand-new filtering and up-conversion to take advantage of this simple, but elegant solution. We name it Marantz Musical Mastering.
Marantz Musical Mastering
DSD is at the heart of the way the SA-10 handles digital audio: PCM and DXD inputs are all upconverted to DSD at 11.2MHz using the proprietary MMM-Stream converter within the player, and then the high-frequency signal produced is processed by the unique MMM-Conversion stage, used in place of a conventional DAC, to produce the analogue output.
Built For Generations
Like its partnering, the PM-10 integrated amplifier, the SA-10 is constructed to the highest possible standards, with a double-layered copper-plated chassis for excellent rejection of mechanical and electrical interference, and casework constructed from thick non-magnetic aluminum panels and 5mm thick top lid. Both products also sit on aluminum machining feet for reduced vibration and allows for a smoother listening experience.
All the details
-
Technical Specifications
Features
CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC Yes / Yes / Yes / Yes / Yes / Yes CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data No / Yes / Yes / Yes / Yes Data Disc Compatibility: DSD / WAV / ALAC <=5.6 / 192 / 96 iPod / iPhone compatible USB input Yes DAC operation mode: USB / Coax / Optical Yes / Yes / Yes Asynchronous mode rear USB Yes Bit-perfect transmission Yes Signal isolator for DAC Mode operation Yes HDAM version HDAM+HDAM SA2 Power Transformer: Toroidal / El Yes / No High Grade Audio Components Yes Customised Components Yes Symmetric circuit layout Yes Copper Plated Chassis Yes Extra metal plate for chassis strengthing Yes Digital out off / Audio EX Mode Yes / No Headphone: Standard / Buffer / Current feedback No / Yes (HDAM SA2+HDAM) / Yes Others
Separated rectifier circuit for analogue and digital circuitry Yes Display: Dimmer / Off No / Yes Low noise LCD display Yes 5mm Aluminum top cover Yes Selectable filter: CD / SA-CD / DAC-Mode Yes / No / Yes Marantz Musical Mastering Yes (HD) Marantz Musical Mastering Stream Yes Marantz Musical Mastering Conversion Yes Playback
Program Play (CD / SA-CD) Yes / Yes Repeat Yes Random Play Yes Start Sound Mode for SA-CD Yes Inputs/Outputs
Analogue Out (Cinch) 2ch Balanced Out Yes Digital Optical In / Out Yes / Yes Digital Coaxial In / Out Yes / Yes Sample Rate digital In 192 kHz / 24-bit Gold Plated Cinch silver / nickel USB Audio (Front) / Made for iPod / Made for iPhone® rear / Yes / Yes USB type B input for PC (rear) Sample Rate USB type B In Yes Asynchronous mode rear USB Yes USB type B input for PC (rear) 384 kHz / 32-bit USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 -> DSD11.2 Headphone Out Yes Headphone Volume Control Yes Specifications
Mechanism SACD-M3 (METAL) D/A Conversion Marantz Musical Mastering Conversion DAC IC Marantz Musical Mastering Conversion Digital Filter DSP (Marantz) Low Pass Filter stage HDAM x 2 Output Buffer HDAM SA2 Frequency Response (Cust.) 2 Hz - 60 kHz Dynamic Range (SA) 109dB Signal to Noise Ratio (SA) 112dB Channel Separation (SA) 105 dB Frequency response 2 Hz - 20 kHz Dynamic Range 98 dB Signal to Noise Ratio 104 dB Total Harmonic Distortion 0.00% Channel separation 100 dB Total Harmonic Distortion (SA) 0.00% General
Available Colors: Gold / Silver / Black / Silver-Gold Yes / No / Yes / No Metal Front Panel Yes Remote Control RC004PMSA Power Consumption in W 50 Standby Consumption in W 0.3 Auto Power off Yes Detachable Power Cable Yes Maximum Dimensions (W x D x H) in mm 440 x 419 x 127 Weight in kg 18.4
