Product Description

• Comes with a three-way, four driver configuration.
• Bespoke 25 mm C-CAM, (Ceramic-Coated Aluminium/Magnesium) tweeter featuring vented Neo magnet system.
• Featutres a specially-developed 4-inch mid-range driver with ‘under hung’ voice coil and motor system.
• Comes with dual 8-inch bass drivers with ‘dished’ C-CAM cone profile for better damping and improved mid-range clarity.
• RST Cone profile for improved diaphragm rigidity and lower distortion.
• Two sets of binding posts allow bi-amping or bi-wiring.
• Comes with removable magnetic grille.

Product features

The Silver 500 7G has a ton of technological advances. Even at high volumes, Rigid Surface Technology II maintains crystal-clear, well-controlled sound. a crossover setup that, if necessary, balances the bass driver and tweeter output. a smooth, steady frequency response that blends well with all musical styles. We could go on, but this is really all you really need to hear. The Monitor audio tower speaker's three-way, four driver layout offers the opportunity to tune drive units for maximum efficiency and minimal distortion, both in terms of electrical and acoustic performance.

The opening notes of your favorite song projected onto a pair of floorstanding Silver-500 speakers. After that, you'll see why it has everything both a casual listener and a die-hard audiophile could ask for. Even at high volumes, Rigid Surface Technology II maintains crystal-clear, well-controlled sound. a crossover monitor tower speaker system that, when necessary, balances the bass driver's and tweeter's output.

C-CAM Gold Dome Tweeter, 1-1/4"

The newly designed 1" C-CAM Gold Dome loudspeaker allows for the complete reproduction of harmonic frequencies that are crucial to precise reproduction by extending the monitor audio floor-standing speaker's frequency response to an ultrasonic 30kHz. An inventive discharge mechanism in the New Silver Tower Loudspeaker allows air to pass past the magnet assembly of the tweeter and into a rear loading chamber, eliminating air compression at the rear of the dome for decreased distortion, decreased mechanical resonance, and enhanced damping.

C-CAM Methodology

The S-500 BY monitor speaker unit uses C-CAM driver technology throughout, which offers a consistent sonic identity and tonal balance over the entering audio frequency band. The aerospace industry invented ceramic-coated aluminum/magnesium as a material for jet engine components. Its characteristics make it perfect for speaker units since it is quite stiff but still light enough to produce excellent overall efficiency. The aluminum/magnesium alloy is subjected to a three-step stress-relieving process during manufacturing in order to eliminate surface deformation and molecular weakness.

Dual-Amping and Dual-Wiring

With bi-amping, you may increase the dynamic range and reduce distortion of your speaker by using different amplifiers for its high and low frequency parts. To maintain the balance of the speaker's voice, we advise that the gain of each of your individual amplifiers be the same.
Your Monitor-audio tower speakers' overall transparency will be noticeably improved with bi-wiring. Connect the low- and high-frequency drivers to different speaker wires from a single amplifier; the high-frequency drivers are connected to the higher set of binding posts, while the low-frequency drivers are connected to the lower set.

Double Binding Posts plated in silver

Two sets of silver-plated binding posts are joined by wire jumpers on the S500 tower loudspeaker. It will be possible to bi-wire or bi-amp the speaker using the twin posts. The bass and treble performance of the speaker can be enhanced by bi-wiring or bi-amping. The jumpers between the terminal posts must be removed if you choose to bi-wire or bi-amp; otherwise, your amplifier and loudspeakers may sustain damage.

Technology via HiVe Port

The HiVe technology used in the monitor audio tower speaker bass ports is designed to have an ongoing effect on airflow similar to that of a gun barrel on a projectile. Air enters and exits the ports more quickly thanks to fluted grooves in the ports, which also help to reduce turbulence and speed up flow. This results in a more dramatic and fast bass response.

Tree 6.5-inch 'dished' subwoofers

A half dozen are used in the floorstanding audio silver-500 half dozen.Two half dozen and a 5" C-CAM midrange/midbass speaker.C-CAM bass woofers, 5"
The newly developed 5.5" "dished" C-CAM cone uses its whole surface area to produce a lot of sound.

Specifications
System Format: 3-way
Frequency Response: 30 Hz – 35 kHz
Sensitivity (1W@1M): 90 dB
Nominal Impedance: 8 Ohms
Maximum SPL: 117 dBA
Power Handling (RMS): 250 W
Recommended Amplifier Requirements: 80 – 250 W
Crossover Frequency: LF: 700 Hz; MF/HF: 2.9 kHz
External Dimensions (H x W x D): 1050 x 230 x 332 mm (41.34 x 9.06 x 13.07 inches) including plinth, spikes add additional height
Weight (each): 20 kg (44 lbs)
Design and Construction
Enclosure Type: Dual chamber, floorstanding with dual HiVe II port technology
Cabinet Construction: High-quality MDF with extensive internal bracing and Radial and Cross-bracing techniques for reduced cabinet resonance and a purer sound.
Finish Options: Available in a range of premium quality finishes to match any room décor, including Black Oak, Walnut, Satin White, and High Gloss Black.
Binding Posts: Bi-wire/ Bi-amp capable high-quality binding posts for flexible and secure connection options.
Plinth Design: Comes with a sturdy plinth for improved stability and floor coupling, reducing unwanted vibrations.
In the Box
2 x Monitor Audio Silver 500 Tower Speakers
2 x Magnetic Grilles
2 x Floor Plinths with Spikes and Rubber Feet
1 x User Manual
1 x Warranty Information
Warranty
Manufacturer's Warranty: 5 years, providing assurance of the speakers' quality and long-term reliability.
The Monitor Audio Silver 500 tower speakers are designed for audiophiles and home theater enthusiasts who demand the best in audio performance and aesthetic design. With their powerful drivers, advanced technologies, and elegant finishes, they deliver an unmatched listening experience that brings your favorite music and movies to life. For more information, please refer to the Monitor Audio website or consult with an authorized dealer.
